Case Study #15: Maxpack Filling and Labeling Machines for the Packaging of Essential Oils, Liquids, and Creams.

CS#15: Maxpack filling and labeling machines for the packaging of essential oils, liquids, and creams

Case Study #15: Maxpack filling and labeling machines for the packaging of essential oils, liquids, and creams.

The project consisted of a Maxpack MBL line to fill bottles with massage oils, sprays, and creams. The client was looking to automate a manual production line to increase installed capacity to support an accelerated growth.

Check out specific details below:

Requirements

Product Types: Oils, sprays, and creams

  • Massage Oil Details:
    • Product Type: Viscous and oily
    • Volumes:
      • Volume 59 ml
      • Bottle size: 88 mm height x 38 mm diameter
      • Volume 118 ml
      • Bottle size: 107 mm height 44 ml diameter
    • Requested Speed: 30 Bottles Per Minute (BPM)
    • Packaging type: Bottle
    • Material Type: PET
    • Fill format: Automatic filling
    • Lid type: lid with pp polycone liner (neck: 20-400)
    • Lid dimensions: 2oz 20-400 neck and 4oz 24-400 neck
  • Mist Spray Details:
    • Product Type: Oily
    • Volumes:
      • Volume 59 ml
      • Bottle Size: 76 mm height x 39 mm diameter
      • Volume 118 ml
      • Bottle Size: 107 mm height x 45 mm diameter
    • Requested Speed: 30 Bottles Per Minute (BPM)
    • Packaging type: Bottle
    • Material Type: PET

Specific requirements and solution:

  • Maxpack MCSP-10 servo piston filler for volume range 50-1000ml
  • Maxpack MPLM-A round servo label machine
  • Rotary infeed and collection tables SS AISI 304# frame structures
  • Conveyor for machine connection SS AISI 304# frame structure and sufficient length for manual capping as the client has many types of caps, including spray pump caps.

Conclusion:

Maxpack gathered all the requirements and concluded that the best fit for this project would be the Maxpack MCSP Servo filling machine with 10 head nozzles and a filling volume range of 50 to 1000 ml and the Maxpack MPLM-A round servo labeling machine for adhesive label types.

The Maxpack packaging technology proposed satisfied all client requirements and even reached above the speed objective of 40 Bottles Per Minute.
